555 MMA 500G Heavy-Duty Stick Welder — 480A MMA, 380V Three-Phase (VRD)
555 MMA 500G Heavy-Duty Stick Welder — 480A MMA, 380V Three-Phase (VRD)
Available on Request — price and UAE stock confirmed on enquiry.
The 555 MMA 500G is a heavy-duty stick (MMA) inverter on a 380V three-phase supply, delivering up to 480A for the heaviest fabrication and a continuous 304A at 100% duty for all-day production. VRD-equipped and cellulosic-capable, it handles everything from pipe root runs to thick structural steel.
Key features
- Process: MMA
- Rated output: 480A / 39.2V / 40% · 304A @ 100%
- Output range: 40–480A
- Input power: 380V / Three Phase / 50–60Hz
- OCV: 68V · VRD equipped
- Cellulosic & low-hydrogen capable
- Weight: 26 kg · 526 × 272 × 468 mm
Compatible electrodes
E6010 / E6011 (cellulosic), E6013, E7014, E7018 (low-hydrogen)
Technical specifications
| Model | 555 MMA 500G |
| Input power | 380V / Three Phase / 50–60Hz |
| Rated output | 480A / 39.2V / 40% · 304A @ 100% |
| Welding process | MMA |
| Output range | 40–480A / 68V |
| VRD | Yes |
| Rated input current | 36.2A @ 480A |
| Electrode compatibility | Acid, basic & cellulosic |
| Dimensions / Weight | 526 × 272 × 468 mm · 26 kg |
